Semi-auto winding machine JY-1DS
Range of use
Precise layer winding machine for segment tooth and big bobbins, such as elevator traction electric motor coil.
Main function
-Semiauto winding machine
-Servo motor for wire precision layer winding.
-HMI operation language:English/Chinese

-Manual load/unload, auto tailstock, manual fix the start lead wire,auto winding, auto precise layer winding, servo motor controlled for precise layer winding. manual wire cut and clamp. Different type of coil winding: only need to exchange the fixtures and saved programs.
Technical specification
|
Machine model |
JY0100 |
|
Traversing width |
≤300mm(customized longer) |
|
Revolution Diameter |
<φ200mm |
|
Wire size range |
0.02mm-3mm |
|
Max wire strands |
10 |
|
Spindle speed |
0-1000rpm |
|
Main motor |
Servo 1000W |
|
X motor |
Servo 200W |
|
Power supply |
AC220V(±5%),50Hz |
|
Air source |
0.5-0.6 Mpa |
|
Gross weight |
200KG |
|
Machine dimension |
800mm(L)×1200mm(W)×1200mm(H) |
Optional parts
- Multistrand wire device
- Electric/magnetic/Mechanical tensioner
- Security cover and sensor.
